MAINTEX Product Catalog
Product description
Driving voltage Driving Voltage (V) |
Resistance Resistance (Ω) |
Inductance Inductance (mH) |
Step Angle Step Angle（°） |
Maximum pull-in frequency Max. Pull-in Frequency (Hz)
|
Maximum pull-out frequency Max. Pull-out Frequency (Hz)
|
Holding torque Holding Torque (gf.cm)
|
Pull-out torque Pull Out torque (gf.cm) |
Detent torque Detent Torque (gf.cm) |
12 | 30 | 18.8 | 7.5 | ≥400 | ≥600 | 300 | 100 | 55 |
