MAINTEX Product Catalog
Product description
Rated Voltage Rated Voltage (V) | Resistance Resistance (Ω)
| Number of Phases Phase
| Reduction Ratio Reduction Ratio
| Step Angle Step Angle (°)
| No-load Pull-in Frequency No-load Pull-in Frequency (Hz) | No-load Pull-out Frequency No-load Pull-out Frequency (Hz) | Pull-in Torque Pull-in Torque (mN.m) | Detent Torque Detent Torque (mN.m) |
24 | 600 | 4 | 1/42.5 | 37.5 | ≥300 | ≥500 | ≥150 | ≥100 |
