MAINTEX Product Catalog
Product description
Model Number Model |
Rated Voltage Rated Voltage (VDC) |
Operating Voltage Range Operating Voltage Range (VDC) | Drive Circuit Drive Circuit |
Control Method Control Mode
|
Rated Torque Rated Torque (N.m)
|
Rated Speed Rated Speed (RPM)
|
Speed Adjustment Range Speed Adjustment Range (RPM)
| Rotation Direction Rotation Direction | Product Application Product Application |
BL6208-01 | 24 | 22.8~25.2 | 3-Phase Full-Wave PWM Drive | 3-Phase Sine Wave | 0.081 | 2600±10% | 500-2600 | CCW | Air Purifier, Bathroom Heater |
